AudioControl ACM-4.300

AudioControl ACM-4.300

$349.99 USD
$349.99 USD
Sale Sold out
Shipping calculated at checkout.
AudioControl comes to the rescue with their compact ACM-4.300 4-channel amp, which delivers 50 watts RMS per channel — perfect for two sets of speakers. This tiny, hand-size amplifier will fit almost anywhere in almost any kind of vehicle, improving the impact and clarity of your music. Even better, it features high-level inputs with signal-sensing turn-on, so it'll work with almost any stereo system, even one using a factory radio.

Product highlights:

  • 4-channel car amplifier
  • 50 watts RMS x 4 at 4 ohms (75 watts RMS x 4 at 2 ohms)
  • 150 watts RMS x 2 bridged at 4 ohms
  • Class D amp technology
  • selectable high-pass filter (bypass, 80, 120 Hz at 12 dB/octave) on front and rear channels
  • subsonic filter: 32 Hz
  • preamp and speaker-level inputs
  • GTO™ (Great Turn On) signal-sensing turn-on with speaker-level input
  • fuse rating: 30A x 1
  • wiring and hardware not included with amplifier
  • 8-gauge power and ground leads recommended
  • dimensions: 9-1/2"W x 1-3/4"H x 3-1/2"D

Specifications:

  • Preamp Inputs: 4
  • Speaker Level Inputs: 4
  • Preamp Input Voltage Range: 500mV - 6V RMS
  • Continuous Output Power (14.4V):
    • 4Ω: 50W x 4 RMS
    • 2Ω: 75W x 4 RMS
    • Bridged 4Ω: 150W x 2 RMS
  • Frequency Response: 10Hz - 22kHz
  • Signal to Noise Ratio: 102 dBA, Ref 50W @ 4O
  • THD+N: <0.01%
  • Fuse Rating: 30A x 1
  • Crossover: 12 dB/octave Linkwitz-Riley, 80Hz/120Hz/Bypass
  • PFM Subsonic Filter: 32Hz
  • Dimensions: Width: 9.44", Height: 1.70", Depth: 3.50"
  • Weight: 1.3 lbs.
